4.2 Ton Capacity Floor-plate 2-Post Lift, Automatic Lock Release

In the world of luxury and expert-grade auto repair, the quality of workshop equipment reflects directly on the quality of service provided. The CAV TP4.2E Floor-Plate 2-Post Lift has been engineered to meet the exacting standards of these premium service environments, where technicians work on high-value vehicles that demand meticulous care and attention.

With a lifting capacity of 4.2 tons, the CAV TP4.2E provides ample strength for the full range of vehicles found in a premium workshop, from long-wheelbase luxury sedans and executive SUVs to high-performance sports cars and light commercial vehicles. This capacity ensures that workshop owners can accept any job with confidence, knowing their lifting equipment is up to the task.

The automatic lock release system is a defining feature of the CAV TP4.2E, setting it apart from manual-release models. Through an intuitive control box, the operator manages both the lifting and lowering operations seamlessly. When lowering is initiated, the safety locks disengage automatically, without any manual intervention required. This fully automated process reduces the risk of operator error, speeds up workflow, and enhances the overall user experience. For workshops that handle multiple vehicles daily, this automation translates to significant time savings and improved efficiency.

Examining the engineering in greater detail, the CAV TP4.2E utilizes a robust chain lifting system paired with high-quality hydraulic cylinders. This combination delivers smooth, powerful, and consistent lifting performance, achieving the full 1800mm lifting height in just 40 to 50 seconds. The synchronization between the two columns is maintained by heavy-duty cables and precision pulleys, ensuring that both sides rise in perfect harmony. This balanced lifting action is essential for protecting the vehicle's chassis and ensuring technician safety during under-vehicle work.

The floor-plate design of the CAV TP4.2E provides a stable, integrated base that connects the two columns at ground level, offering enhanced structural rigidity while keeping the workshop floor clear of overhead cables. The 2+2 lifting arms, with automatic locking, adapt to a wide range of vehicle chassis configurations, providing secure support at manufacturer-recommended lifting points. The maximum lifting height switch adds an important safety layer, automatically cutting motor power at the upper limit to protect hydraulic cylinders from over-extension. Perhaps the most compelling testament to the CAV TP4.2E's quality is its testing regime. Each lift passes a 115% rated capacity dynamic loading test and a 150% static loading test, confirming that this equipment is built to handle real-world demands with a substantial margin of safety.


Product highlights

• 4.2 Ton Lifting Capacity – Expert-Grade Performance: The CAV TP4.2E delivers a generous 4.2-ton lifting capacity, making it suitable for the demanding environment of luxury and expert-grade repair shops. This capacity handles long-wheelbase SUVs, executive sedans, and light commercial vehicles with ease. For workshop owners who service high-value vehicles, the CAV TP4.2E provides the strength and stability needed to work with confidence.


• Automatic Lock Release System – Effortless Operation: The fully automatic lock release system is a standout feature that simplifies the entire lifting and lowering process. Controlled via a user-friendly control box, the operator initiates the descent, and the safety devices reset automatically. This eliminates the need for manual release handling, reducing the risk of human error and accelerating service times. The automated operation is particularly valued in busy workshops where efficiency and consistency are priorities.


• Rigorous Load Testing – 115% Dynamic and 150% Static: Every CAV TP4.2E lift undergoes demanding testing procedures that exceed standard requirements. The 115% dynamic loading test verifies the lift's performance under moving loads, while the 150% static loading test confirms the structural integrity of the unit under extreme stationary loads. These tests provide workshop owners with measurable assurance that the lift is engineered with a substantial safety margin, offering reliability far beyond its rated capacity.


• Strong Synchronization Cables and Pulleys for Balanced Lifting: The CAV TP4.2E features heavy-duty synchronization cables and precision pulleys that maintain perfect alignment between both columns throughout the lifting cycle. This balanced lifting is critical for protecting vehicle frames and ensuring a stable working environment. The robust construction of the synchronization system ensures long-term reliability, even under the demanding conditions of a busy luxury workshop.


• 2+2 Lifting Arms with Automatic Locking: The CAV TP4.2E comes equipped with 2+2 lifting arms, offering two arms on each side that accommodate a broad spectrum of vehicle sizes and chassis designs. The automatic arm locking system engages once the arms are positioned, holding them securely in place throughout the service. This feature ensures stable support and prevents arm movement during the lifting process.


• Chain and Hydraulic Cylinder Drive System: The proven combination of a chain drive system and high-quality hydraulic cylinders delivers consistent lifting power with minimal maintenance. The chain mechanism is engineered for durability, while the hydraulic cylinders provide the force needed for smooth, controlled lifting. This drive system has been selected by CAV for its dependability in professional workshop environments.


• Maximum Lifting Height Switch for Operational Safety: The integrated maximum lifting height switch automatically cuts power when the carriage reaches the upper limit, protecting hydraulic cylinders from over-extension and ensuring safe operation. This feature provides an additional layer of protection for both the equipment and the vehicles being serviced.
