Leverless Automatic Tire Changer 13"-28"

The CAV 1028 EVO leverless automatic tire changer represents a significant step forward in tyre service technology. CAV knows that traditional tyre changing methods rely heavily on manual levers, which require physical strength, can damage wheels if used incorrectly, and slow down the overall service process. That is why CAV developed the EVO series with a leverless design – a smarter way to mount and dismount tyres that reduces physical strain and speeds up the workflow.

The leverless operation on this tire changing machine works differently from conventional machines. Instead of using a manual lever to pry the tyre over the rim edge, the CAV 1028 EVO uses a specially designed tool head and turntable action that guides the tyre bead smoothly onto or off the rim. The technician simply positions the tool, and the machine does the heavy lifting – no wrestling with levers, no awkward prying motions, no risk of slipping and damaging the wheel. This makes the CAV 1028 EVO particularly valuable for workshops that handle a high volume of tyres, or for technicians who may not have the physical strength to work with manual levers all day long.

The clamping range on this automatic tire changer is impressively versatile. External clamping goes from 10" to 22", and internal clamping covers 12" right up to 28". Maximum wheel diameter is 1150mm (45 inches), and maximum width is 410mm (16 inches). That means you can service everything from compact passenger car wheels through to light truck, van, SUV, and even agricultural tyres on the same machine. It is one of the most versatile leverless tire changers on the market.

The automatic bead breaker delivers 2500kg of force, handling stubborn beads on old tyres, corroded rims, and stiff sidewalls with confidence. Foot-pedal controls give the operator hands-free operation of the turntable and tool arm, while the multi-angle duckhead tool is designed to protect rims from scratches and damage. The machine runs on a motor rated at 0.55kW, 0.75kW, or 1.1kW depending on your local supply, with configurations for 110V, 220V, or 380V. Noise level is kept under 70dB, and air supply requirements are 8 to 10 bar. The heavy-gauge steel frame and reinforced tower provide the stability you need when working on larger wheels.

Product highlights

Leverless Operation – This is the defining feature of the CAV 1028 EVO automatic tire changer. Traditional tyre changers rely on manual levers that require physical strength, can damage wheels if used incorrectly, and slow down the service process. The leverless design eliminates these issues by using a specially engineered tool head and turntable action that guides the tyre bead smoothly onto or off the rim. Technicians no longer need to wrestle with levers – the machine does the hard work. This reduces fatigue, speeds up service times, and minimises the risk of damaging expensive wheels. For workshops handling high tyre volumes, the leverless operation is a genuine productivity boost.

Versatile Clamping Range – 10" to 28" – The CAV 1028 EVO tire changer covers an exceptionally wide range of wheel sizes. External clamping goes from 10" to 22", and internal clamping covers 12" to 28". Maximum wheel diameter is 1150mm (45 inches), and maximum width is 410mm (16 inches). That means you can service everything from compact passenger cars through to SUVs, light trucks, vans, and even agricultural machinery on the same tire changing machine. This versatility reduces the need for multiple machines in the workshop.

Powerful 2500kg Automatic Bead Breaker – The bead breaker on the CAV 1028 EVO delivers 2500kg of force, handling stubborn beads on old tyres, corroded rims, and stiff sidewalls with ease. The bead breaker operates automatically, giving consistent, reliable performance that reduces physical strain on technicians. On larger tyres with thick sidewalls, this power is essential for efficient service.

Extra-Wide Wheel Capacity – Up to 410mm – The CAV 1028 EVO handles wheels up to 410mm wide, significantly wider than standard tire changers. That extra width capacity means you can work on the widest tyres found on SUVs, light trucks, and agricultural equipment without struggling to fit them into the clamps.

Heavy-Gauge Steel Frame Construction – The CAV 1028 EVO is built with a massive steel frame and a reinforced tower that takes the stress of daily tyre work. This heavy-duty tire changer stays rock-solid and stable even when you are applying maximum force to break stubborn beads or using the leverless tool head. CAV has over-engineered the structure to handle the rigours of a busy workshop.

Foot-Operated Pedal Controls – The foot pedal system gives total hands-free control over the turntable rotation and the tool arm. You can rotate the wheel, position the tool, and guide the tyre all without taking your hands off the job. This is a significant safety and efficiency feature, especially when working with larger wheels.

Multi-Angle Duckhead Tool – The duckhead tool is designed to protect expensive wheels from scratches and damage. The multi-angle head gives flexibility to approach the tyre from the optimal position, reducing effort and minimising the risk of marking the rim. This is especially important when working with alloy wheels or powder-coated rims.

Low Noise Operation – Below 70dB – At under 70 decibels, this automatic tire changer is quieter than many competitors, creating a more comfortable workshop environment.

Integrated Tool Tray – The built-in tray keeps tyre tools, valve stems, and accessories organised and within reach, keeping your workspace tidy.

Flexible Power Supply Options – CAV offers this tire changer with motor ratings of 0.55kW, 0.75kW, or 1.1kW to suit your local power supply – choose from 110V, 220V, or 380V configurations.
